  • Vacuum Feeder

Vacuum Feeder

Vacuum feeder, also known as vacuum conveyor, is an efficient pipeline conveying equipment designed for transporting granular and powdery materials in dust-free and enclosed environments. This technology guides material flow through vacuum and pressure difference, and is widely used in multiple industries such as chemical, pharmaceutical, and food. Its closed pipeline design effectively avoids dust pollution, improves the cleanliness of the working environment, saves space, and adapts to various transportation distances. The vacuum feeder reduces manual labor intensity and improves work efficiency, making it an ideal choice for conveying powder materials.

Product advantages
Parameters
ModelMotor power(kw)Transportation capacity(kg/h)
WZKS-4001.5400
WZKS-6002.2600
WZKS-120031200
WZKS-25005.52500
WZKS-32005.53200
WZKS-60007.56000

working principle

Advanced design:The vacuum feeding machine adopts advanced design, consisting of a vacuum pump (oil-free, waterless), a multi option filter (including polyester film, PE, 316L stainless steel or titanium metal filters), a compressed air blowback device, a pneumatic discharge door, a material level automatic control device, a stainless steel suction nozzle and a conveying hose, etc. The device generates negative pressure through a vacuum pump, creating a vacuum airflow that sucks in materials and transfers them to the silo through a suction tube. The filter effectively separates materials from air. When the silo is full, the controller automatically stops the vacuum generator and opens the silo door to smoothly unload the materials to downstream equipment. This system provides an efficient, hygienic, and automated material handling solution.
